AR1901

AR1901 | Specifications for ANTRACK V2-EC2-DT

  Product Glance
Value Model
ANTRACK V2-EC2-DT Version
V2-EC2-DT Capacity
4 units ANTMINER (Hydro) or
4 units ANTMINER (U2 Hydro) or
2 units ANTMINER (U3 Hydro) Maximum load,kW
24   Detailed Characteristics
Value Part 1: Mining Cabinet Hardware Configuration Size (Length*Width*Height), mm (without package)
1200*600*1200 Size (Length*Width*Height), mm (with package)
1320*710*1340 Net weight, kg (without package)
120 Gross weight, kg (with package)
195 Network connection mode
RJ45 Ethernet 10/100M Power Supply Power supply AC Input voltage, Volt(1-1)
380~415V AC Power supply AC Input Frequency Range, Hz
50~60 Power supply AC Input current, Amp(1-2)
63 Water pump Rated power, W
450 Noise, dBA@1m
60 Lift, m
19 Size (Length*Width* Height), mm
360*210*268 Part 2: External Cooler(1-3) Hardware Configuration Size (Length*Width*Height), mm (without package)
1200*650*1180 Size (Length*Width*Height), mm (with package)
1320*710*1340 Net weight, kg (without package)
90 Gross weight, kg (with package)
160 Power supply Power supply AC input voltage, Volt(1-1)
380~415V AC Power supply AC input frequency range, Hz
50~60 Maximum power supply AC input current, Amp(1-2)
63 Fan Rated power, W
750 Noise, dBA@1m
64 Size (Length*Height*Thickness), mm
850*850*305 Environment Requirements Ambient temperature, °C
-20~40 Water flow, L/min
32.0~40.0 Water pressure, bar
≤3.5 Working fluid(1-4)
Antifreeze (10%) Installation distance, m(1-5)
5 Liquid PH
7.8~8.5 Storage temperature, °C
-20~70 Operation humidity(non-condensing), RH
10~90% Notes:
(1-1) Caution: Wrong input voltage may cause server damaged.
(1-2) Three-phase AC input.
(1-3) The External cooler should be placed outdoors in a well-ventilated environment.
(1-4) If the water conductivity is ≥100 μs/cm, the fluid must be replaced. The water conductivity is less than 20 μs/cm when the system is running at the first time.
(1-5) The distance between mining cabinet and external cooler.

| Specifications for S19 XP+ Hyd.

  Product Glance
Value Model
S19 XP+ Hyd. Crypto algorithm/coins
SHA256 | BTC/BCH/BSV Typical hashrate, TH/s(2-1)
279 Power on wall @35°C(2-2), Watt(2-1)
5,301 Power efficiency on wall @35°C(2-2), J/TH(2-1)
19 Detailed Characteristics
Value Power Supply Phase
3 Input voltage, Volt(3-1)
380~415 Input Frequency Range, Hz
50~60 Input max current, Amp
12 Hardware Configuration Networking connection mode
RJ45 Ethernet 10/100M Server Size (Length*Width*Height, w/o package), mm
339*173*207 Server Size (Length*Width*Height, with package), mm
570*316*430 Net weight, kg
12.3 Gross weight, kg
13.6 Environment Requirements Inlet coolant temperature,°C

20~50 Coolant flow, L/min

8.0~10.0 Coolant pressure, bar

≤3.5 Working coolant(3-2) Antifreeze/ Pure water/Deionized water Coolant pH value Antifreeze: 7.0~9.0
Pure water: 6.5~7.5
Deionized water：8.5~9.5 Diameter of coolant pipe connector, mm

OD10 Storage temperature,°C
-20~70 Operation humidity(non-condensing) , RH
10~90% Notes:
(2-1) The hashrate value, power on wall, and power efficiency on wall are all typical values. The actual hashrate value fluctuates by ±3%, and the actual power on wall and power efficiency on wall fluctuate by ±5%.
(2-2) Inlet coolant temperature.
(3-1) Caution: Wrong input voltage may cause server damaged.
(3-2) For detailed working coolant use and maintenance instructions, please refer to “ANTSPACE HK3 Hydro Cooling Container & Dry-Wet Tower Product Manual”, Chapter 9, Article 3, Point 6, “Maintenance of Coolant”! | Purchasing Guidelines

1. The ANTRACK is recommended to be used simultaneously with the Hydro-cooling ANTMINERS.
2. The pictures shown are for reference only; the final shipment version shall prevail.
3. Contact Customer Service Robot to review the shipping cost.
4. After an order has been submitted, a request to cancel the order, refund any part of the ordered amount or change the ordered item(s) to different item(s) or different batch(es) will not be entertained by BITMAIN.

| Shipping Details

1. Shipments will be scheduled on a first-paid-first-ship basis for orders on which BITMAIN has received full payment.
2. You are responsible for any customs delays or returned shipments due to a lack of proper documentation. It’s highly recommended to be aware of local customs clearance policies and prepare all customs documentation ahead of time to avoid delays or unexpected costs.
3. Click here to download Certificates of Conformity and find additional information on customs clearance for BITMAIN products. | Warranty

1. A 365-day warranty period is provided starting from the shipping date. BITMAIN will cover shipping costs when shipping a replacement unit within the warranty period.
2. The warranty only applies to the original purchaser who purchased the machine directly from BITMAIN. Once the miner is resold, warranty coverage becomes the responsibility of the re-seller.
3. If the user fails to use the product per the given instructions, specifications, and conditions provided or changes the function settings of the unit without BITMAIN’s prior consent, BITMAIN will not be liable for any damage arising therefrom.
4. Click here for a complete list of the Terms & Conditions that apply to all orders placed on https://mining-now.xyz.
