AFC02-AZ（10）

AFC02-AZ（10） | Specifications Product Overview
Value Model
AFC02-AZ Version
V1.0 Dimensions (l*w*h), mm
1200*1000*1160 Shipping Weight, T
1.14 Detailed Characteristics
Value Color
Blue/Red clear liquid Odor
Asexual odor PH
8.0~9.0 Conductivity, µS/cm
2400-4000 Reserve alkalinity, mL
>2.5 Turbidity, NTU
<1 Freezing point, ℃
-40 Glycol volume concentration
53% Density, kg/L
1.070-1.078 Thermal conductivity@20℃, W/m.K
0.352-0.406 Specific heat capacity@20℃, kJ/kg.K
3.190~3.229 Relationship between antifreeze glycol concentration and freezing point Glycol volume concentration, %
Freezing point, ˚C 0
0 5
-1.6 10
-3.7 15
-6.1 20
-8.9 25
-12 30
-15.4 35
-20.3 40
-25.3 45
-31.1 50
-36.4 55
-44.2 60
-54 | Purchasing Guidelines

1. The ANTSPACE AZ needs to be replaced every three years.
2. The pictures shown are for reference only; the final shipment version shall prevail.

| Shipping Details

1. Shipments will be scheduled on a first-paid-first-ship basis for orders on which BITMAIN has received full payment.
2. You are responsible for any customs delays or returned shipments due to a lack of proper documentation. It’s highly recommended to be aware of local customs clearance policies and prepare all customs documentation ahead of time to avoid delays or unexpected costs.
3. Click here to download Certificates of Conformity and find additional information on customs clearance for BITMAIN products. | Warranty

1. A 365-day warranty period is provided starting from the shipping date. BITMAIN will cover shipping costs when shipping a replacement unit within the warranty period.
2. The warranty only applies to the original purchaser who purchased the machine directly from BITMAIN. Once the miner is resold, warranty coverage becomes the responsibility of the re-seller.
3. If the user fails to use the product per the given instructions, specifications, and conditions provided or changes the function settings of the unit without BITMAIN’s prior consent, BITMAIN will not be liable for any damage arising therefrom.
4. Click here for a complete list of the Terms & Conditions that apply to all orders placed on https://mining-now.xyz.
