APW11I1216-1a,12V-16V,V1.0

APW11I1216-1a,12V-16V,V1.0 Note:
You can check the exact version at the product tag which is on the side of the power supply and find the newest firmware accordingly through Mining Now Support: Firmware Download OUT1
DC Voltage
12V-16V Rated current (three-phase 380V input)
356A Ripple & Noise
<1% Source adjustment rate
<1% Load Regulation
<1% Start-up and rise time
<20S Power-off retention time
>5mS OUT2
DC Voltage
12.3V Rated current (three-phase 380V input)
21A Ripple & Noise
<1% Voltage Accuracy
12.2V-12.4V Source adjustment rate
<1% Load Regulation
<1% Start-up and rise time
<20S Power-off retention time
>10mS Input
Voltage Range
380-415V AC Frequency Range
50/60Hz Power Factor
>0.99(full load) Leakage Current
<3.5mA（380V 50/60Hz） Protection
Input undervoltage protection value
320-340V AC Output Short Circuit
Yes Over-temperature protection
Yes Output overcurrent protection value
380A-460A （protection value varies under different voltage） Environment
Operating Temperature
20-50℃ Operating Humidity
20%-90%RH（non-­condensing） Altitude
< 2000m Structure
Dimensions
319.6mm*290mm*80mm Net Weight
6.4Kg Cooling method
Immersion Cooling Noise
/ Purchasing Guidelines
